Tech Spec Template.

Schematics

The purpose of a technical design document is to aid in the critical analysis of a problem and the proposed solution, while also communicating priority, effort, and impact with various stakeholders.

A good design doc will preempt questions and queries that might arise during the code review process, identify edge-cases, and will allow people to suggest improvements before a lot of work has been done.

Each section in this post mirrors a section in your design document, it’s a variation on the technical documents I wrote at Google and brought to the engineering team at Medium and Range. You may find that some sections aren’t relevant to all teams and projects, so use what is helpful and drop the rest.

Overview

Start at the beginning. What problem are you trying to solve? If you jump straight into solutions, it will be hard for people to orient themselves and will inevitably lead to misalignment and misunderstanding. It’s worth spending 2 or 3 sentences effectively setting the context for your spec.

Then, briefly state your proposed solution. This should be enough for most people to decide whether they should continue reading and should be understandable by someone who is not familiar with the project. Between a few sentences and two paragraphs should be enough.

Background

It’s unlikely that writing the design document is the first time you’ve thought about the problem. The background section is an opportunity to bring readers up to speed, and share the context you have on the problem space.

What are the motivations for the project or design? Is there any historical perspective that will help people understand the proposal? Has someone tried to solve the problem in the past? If so, why are those solutions no longer appropriate? Are there any other things going on that will affect the design?

Goals, non-goals, and future goals

In order to build alignment and communicate a definition of done, it is important to clearly articulate the goals of this work. The best goals are simple, truthy sentences that describe a future state of the world. Unlike an OKR, it’s fine for these goals to be hyper-specific.

Projects will often have 3-5 goals.

Examples:

Non-goals

As well as explaining what you want to achieve, it is equally important to say what you are explicitly not addressing. These can sometimes be hard to identify, but imagine what another person might expect to be coupled with this work.

Future goals

Future goals are an opportunity to list things you want to do in the future but have descoped for this phase of the project. In other words, these are things you want to make sure your solution doesn’t accidentally make difficult or impossible.

Detailed design

This is the meat of the technical documentation and also the most variable. Depending on the project, the size of your team, or number of stakeholders, it may be a few paragraphs or a few pages. It will often contain pseudo-code, schema definitions, or flow diagrams.

Here are some common questions that get answered as part of the detailed design:

(You probably don’t need to answer all of them.)

Third-party considerations

Today it is common to rely on third-party platforms to support our development work, whether this be part of AWS or GCP, or a whole separate service. It’s worth thinking through the implications of using a third-party and looking ahead for potential future issues.

The cost of these services is often less than an engineer’s time, but sometimes it can scale unexpectedly. Quickly think through how the service is billed and do a back-of-the-envelope calculation of what could be expected once the service is fully rolled out.

While security and privacy considerations were addressed in the detailed design, when using a 3rd party there are specific things to think about and call out.

For example, if the third-party is being used to perform operations on customer data they will likely be considered a subprocessor under the EU’s General Data Protection Regulation (GDPR). So, do you need a data processing addendum? Do you need to collect and review SOC2 reports? Sometimes customers will require notification of new subprocessors, which will affect the roll-out plan below.

Work estimates

For non-trivial changes, provide a breakdown of the work and tasks. How long will each phase take? What work is parallelizable? What dependencies on other teams are there?

Roll-out plan

It’s unusual that you can roll out your project as a single change. In this section, discuss how changes to models and APIs will need to be staged. Will you be rolling out incrementally to your users using feature flags?

Discuss your revert path. If something goes wrong, how will you back out partway through the process while leaving systems in a healthy state? Identify the biggest risks you see, and spell out how you’ll detect and mitigate them.

Alternative approaches

It’s not enough just to share your chosen solution. By explaining approaches that you rejected you can reduce time handling objections from other stakeholders and focus the discussion on your chosen design. Make sure to explain why other approaches seemed inferior or wouldn’t work.

It’s also not unusual for information to emerge during the design process that escalates an alternative approach to the primary approach. If this happens, try and avoid the sunk cost fallacy.

Are there products — internal or external — that are similar to this project? Are other teams being faced with similar challenges?

As an example, if you are building your own NoSQL database (😱) this section might include a feature matrix comparing your technical requirements to existing database offerings.

Future work

This is where you can help prevent bike-shedding and scope creep. Identify anything you’re not addressing with this particular design but that should happen in the future or that would be a logical follow-on project? This is often a more detailed description of the future goals, or perhaps how some of the non-goals might be addressed in the future.

When you’ve written your first draft, go back and reread it. Question each statement and decision. If the reasoning is not clear, add more clarification.

Wrapping up

I’ve seen this template help software engineers of all levels — I even used it to help me think through a solution to a data analysis problem we have here at Range.

I’ve also seen people react negatively to the idea of technical design docs, and to be fair, for many teams and environments, a lot of projects don’t really need technical documentation. Unfortunately, there’s no hard and fast rule on when a spec is appropriate. It’s a function of complexity, certainty, and risk, and is something you’ll have to feel out for yourself.

But, next time you’re working on a gnarly problem, or juggling multiple stakeholders, try using this template, and let me know how it goes.
